Gold Wash Plant

Gold wash plant mainly applies to alluvial gold ore washing. Alluvial gold ore is mainly mined from land surface or river or underground. Has various types of gold raw material: alluvial gold/placer gold/sand gold/river gold/ gold tailing, etc. The main process includes feeding, washing, sieving, rough separation, final concentration, and refining. Because the gold density is much bigger than other minerals, so mainly use gravity separation.

Pre-sales service:

We provide you with the prophase plan, process flow design, and manufacturing equipment according to your special demand.

After-sales service:

We will regularly pay a return visit to customers. Supplying technique, building design, instruction, installation and debugging for free.

Sales service:

Send technicians to the job site guiding the installation and adjustment, training operators and finishing the check and accept together with you.

Lifelong service:

One year warranty to make sure your machine runs constantly. Always offer lifelong service and provide spare parts for a long term.

Gold wash plant for sale

Process Description:
Feeding: have various kinds of feeding way, depends on the plant and material conditions . have choices of vibration feeder, hopper, belt feeder, or wheel loader and excavator feed directly. Usually will make some grizzly bar on feeding machine or hopper to remove big waste stones
Washing: this process is for wash clean the clay and mud in raw material, most popular used are gold trommel scrubber washer and gold washing trommel screen.
Gold trommel scrubber is for washing raw material that with much sticky clay, trommel screen is for wash raw material that with no sticky clay.
Sieving: after washing, need to sieve out some bigger waste material, the under-screen slurry will go to the next machine. This process can use a trommel screen or vibration screen or high-frequency vibration screen.
Primary concentration: this process is for rough gold concentration, can use gold centrifugal concentrator or gold jig separator. The concentrated ore from them will go to final concentration machine.
Final Concentration: the concentrated ore from jig machine or centrifugal will go to gold shaking table for the gold final concentration, can get high purity gold.

Tailing recovery: usually will use a gold sluice box to recovery tailings that coming from centrifugal machines. So can get more gold.
Refining: if some customer needs very very high purity gold and need to smelt to the gold bar for sale, they can use a gold smelting furnace to smelt gold dust to the gold bar.

gold wash plant flowsheet 3D by JXSC Mining

300TPD Gold wash plant equipment List

No. Equipment name Unit Qty
1 Gold trommel SET 3
2 Centrifugal Concentrator SET 6
3 Sluice box SET 3
4 Shaking table SET 3
5 Conveyor belt SET 2
6 Water pump SET 4
7 Slurry pump SET 2
8 gold smelting furnace SET 2
